HK 169
- Stand-alone grenade launcher with G36 buttstock interface
- Ladder sight for ranges up to 350 metres in 50 metre increments
- Mechanical sight for short distances from 50 to 150 metres
- Picatinny rail as per MIL-STD-1913 for mounting tactical accessory components, such as forward grip
Specifications
Caliber
40 mm x 46
Modes of Fire
Semi-Auto
Max Effective Range
350 m
Max Length
665 mm
Max Width
103 mm
Height
211 mm
Barrel Length
280 mm
Weapon Weight
2.2 kg
Chassis
The HK169 features a compact, standalone frame designed for durability and ergonomic handling in a portable launcher configuration.
Operation
It operates as a single-shot, breech-loading system intended for controlled deployment of compatible munitions.
Slide
The HK169 does not use a slide; instead, it incorporates a pivoting barrel mechanism for loading and unloading.
Maintenance
Routine maintenance involves clearing the launcher and cleaning and inspecting the barrel and moving components to ensure reliable operation.
