MG421
Advanced hydraulic recoil management system
Modular pistol grip available in full-automatic configuration or as a selectable single-fire/full-automatic combination
Cross-coding system prevents incorrect assembly of grip and bolt components
Designed to withstand barrel obstructions in accordance with NATO AC225/D14 standards
Safety selector can be engaged in all bolt positions
Weapon can be charged while in the secured (safe) state
Over-the-beach operational capability
Bolt lock function in the event of pistol grip breakage, deformation, or absence
Catch notches allow intermediate bolt positions during incomplete recoil or loading cycles
Quick-change barrel with locking mechanism and three detent positions: folded, barrel-change, and carrying/firing
Visual loaded-state indicator integrated into the receiver cover
Low-maintenance, highly reliable system designed for extreme high and low temperatures in compliance with NATO AC225/D14
Fully ambidextrous safety lever
Ergonomic, non-reciprocating charging handle
Receiver cover supports high load capacity at a 50° opening angle
Two-step belt pull system ensures reliable feeding, including with hanging ammunition belts
NATO STANAG 4694 mounting profile (12 o’clock position) on the receiver cover
Three-stage gas regulator:
[S] Suppressor mode (non-back-pressure-reduced suppressor)
[N] Normal operation / back-pressure suppressor mode
[H] Adverse conditions mode
- Quick-detach (QD) suppressor interface
- Compatible with FN MINIMI 5.56/7.62 and GPMG mounting interfaces
- Ammunition feed compatible with NATO M13/DM60 disintegrating belts from 60- or 120-round belt pouches
Specifications
Caliber
7.62 mm x 51 NATO
Belt Pouch Capacity
60/120 Rd
Trigger Pull
35-80 N
Rate of Fire
650-780 Rd/min
Muzzle Velocity
730 m/s
Muzzle Energy
2540 J
Max Length
958 mm
Width
125 mm
Barrel Weight
1.7 kg
Weapon Weight
8.3 kg
Barrel Length
13", 16.5", 22"
Height
240 mm
Chassis
The MG421 features a lightweight, modular receiver design that provides durability and supports accessory integration.
Operation
It operates using a gas-operated system with a rotating bolt to ensure reliable cycling during sustained fire.
Bolt Carrier Group
The MG421 uses a reciprocating bolt carrier assembly within the receiver to chamber and extract cartridges during operation.
Maintenance
Routine maintenance involves clearing the firearm and cleaning and lubricating the bolt group, barrel, and gas system to maintain consistent performance.
