MP5 SD6
- Extremely reliable, precise and safe-to-use submachine gun, thanks to roller-delayed blowback
- Capable of withstanding barrel obstructions as per NATO AC225/D14
- Over-the-beach (OTB) capability
- The weapon can be set to safety in any loading state.
- NATO STANAG 4694 clamping profile rail for mounting sights and sighting accessories
- HKey handguard
- Tool-free assembly/disassembly of the main assembly groups at user level
- Modular pistol grip interface for using different trigger group combinations
- Modular buttstock interface for the use of different buttstock designs
- Tri-lug interface for QD silencer application
- HK precision barrel made of cold hammer-forged and hard chrome-plated special steel
- Battle-proven submachine gun of numerous law enforcement authorities, armed forces and special forces of NATO/ NATO partners
Specifications
Caliber
9 mm x 19
Magazine Capacity
15/30 Rd
Modes of Fire
Semi-Auto / Full Auto / 3 Round Bursts
Rate of Fire
700 Rounds/min
Muzzle Velocity
300 m/s
Muzzle Energy
360 J
Length Max
800 mm
Width
60 mm
Height
230 mm
Barrel Length
146 mm
Weapon Weight
2.9 kg
Magazine
170 g
Operation
It uses Heckler & Koch’s roller-delayed blowback operating system, firing 9×19 mm Parabellum cartridges from a closed bolt for smooth, controllable cycling in semi-automatic and automatic modes.
Chassis
The MP5 SD6 is built on the classic MP5 submachine gun receiver and chassis, providing a rugged and compact platform with space for an integral silencer and retractable stock.
Slide
Instead of a traditional pistol slide, the MP5 SD6 employs a reciprocating bolt and carrier assembly within the receiver that travels rearward to extract and eject spent cases and forward to chamber fresh rounds during firing.
Maintenance
Routine maintenance for the MP5 SD6 involves safely clearing the weapon, disassembling key components, and cleaning and lightly lubricating the bolt, barrel, and suppression assembly to help ensure reliable performance.
