MP7 A2

  • Personal Defence Weapon (PDW) in high-performance calibre 4.6 mm x 30. Penetrates NATO CRISAT protection (1.6 mm titanium plate + 20 layers of Kevlar) at 200 metres with steel-core ammunition
  • Concealed/partially concealed carry similar to a pistol with HK multi-functional holster
  • Variable firing positions: one-handed, two-handed - standing, prone, kneeling - with buttstock extended or retracted
  • Firing pin safety (drop test as per NATO AC225/D14)
  • Capable of withstanding barrel obstructions as per NATO AC225/D14
  • The weapon can be set to safety in any loading state.
  • Picatinny rail for mounting sights and sighting accessories
  • Day/night combat capability (image intensifier/thermal imaging)
  • Low sighting line to reduce exposure in protected position
  • Tool-free assembly/disassembly of the main assembly groups at user level
  • Compact dimensions, low overall weight
  • Magazine feed in grip assembly for 20, 30 and 40 round magazines
  • U-shape Picatinny handguard (3, 6 and 9 o'clock)
  • Silencer use prepared ex works
  • HK precision barrel made of cold hammer-forged and hard chrome-plated special steel
  • Colour variant green-brown and black
  • Field-proven submachine gun of police and special forces of NATO/NATO partners


Specifications

 Caliber
4.6 mm x 30

 Magazine Capacity
20/30/40 Rd

 Max Effective Range
200 m

 Rate of Fire
950 Rd/min

Muzzle Velocity
680 m/s

 Muzzle Energy
465 J

 Length Max
640 mm

 Width
55 mm

 Height
170 mm

 Barrel Length
180 mm

 Weapon Weight
2 kg

 Magazine Weight
100 g

Operation

It operates on a gas-operated, short-stroke piston system with a rotating bolt, firing the proprietary 4.6×30 mm cartridge from a closed bolt for controllable semi-automatic or full-automatic fire.

Chassis

The MP7 A2 uses a compact, lightweight polymer and metal chassis that integrates the pistol grip and magazine well while incorporating full Picatinny (MIL-STD-1913) rails on the handguard for mounting accessories like lights, lasers, and grips.

Slide

Instead of a pistol-style slide, the MP7 A2’s working assembly uses a reciprocating bolt and carrier inside the receiver that travels rearward to extract and eject spent cases and forward to chamber fresh rounds during firing.

Maintenance

Safely clearing the weapon, field-stripping key components such as the bolt and gas system, and cleaning and lightly lubricating moving parts to help ensure reliable performance and longevity.
